Root ZX3 - Advanced, New Approach for Canal Treatment
Root ZX3 - Advanced, New Approach for Canal TreatmentApex LocatorUnit Includes: Probe Cord, File Holders (3), Contrary Electrodes (5),"AA" Alkaline Batteries (4)Root ZX3 HF ModuleUnit Includes: Wide Contrary Electrodes (3), Foot Switch, Grip, Grip Cap, HF Probe CordHF Relay Cord, AC Adapter, Battery Pack, HF Tip Holder, HF File Holders (3),HF Endo Tip Electrode K#10 (2), HF File Electrode K#10L25 (2)HF Cutting Tip No. 1 ElectrodeQuantity 3-9 UnitsHighlights:Apex Locator with High-Frequency (HF) Module Root ZX3 is the latest generation of Morita's world-renowned apex locator product line. Housed in a brand new, sleek design, it offers an overall smaller footprint, yet a larger, high-contrast display screen. It utilizes Morita's industry-leading apex location technology with real-time readings smoothly displayed by 40 indicator bars.As an optional attachment, the new HF Module snaps easily onto the back of the apex locator. By introducing high-frequency conduction (HFC) therapy, this module offers a new treatment approach for root canal shaping and cleaning methods. Applications and benefits include:Cauterization of pulp in initial treatmentCauterization of pulp in retreatment of challenging cases that could not be addressed solely by conventional methodsHFC's superior hemostatic affect contributes to enhanced apex location precisionDiscover a new world of root canal treatment with Root ZX3.Features:Utilizes Morita's industry-leading, reliable apex location technology, which has been independently evaluated at a 97.5% accuracy rate*Full functionality in dry or wet canalsAutomatic calibration to compensate for changes in environment (temperature, humidity, etc.) and agingHigh accuracy that lasts decades* Tested with Root ZX II.Guise, G. M., Goodell, G. G., & Imamura, G. M. (2010). In Vitro Comparison of Three Electronic Apex Locators. Journal of Endodontics, 36(2), 279-281.
Apex Locator Module
HF Module
Name
Root ZX3
Model
RZX3
Type
Apex Locator Module
HF Module
Dimensions
Length x Width x Height (Approx.)
3.35" x 3.74" x 3.94"
85mm x 95mm x 100mm
Length x Width x Height (Approx.)
4.13" x 3.74" x 3.54"
105mm x 95mm x 90mm
Length x Width x Height (Approx.)
4.33" x 3.74" x 3.94" | 110mm x 95mm x 100mm
(Apex Locator + HF Module)
Weight
Approx. 390 g/13.8 oz
(with dry batteries)
Approx. 360 g/12.7 oz
Approx. 550 g/19.4 oz (Apex Locator Module + HF Module)
Power Rating/ Power
Consumption
Solo operation:
DC 6 V (alkaline dry batteries [AA size], Qty: 4)
Connected with HF Module:
DC 9.6 V (Ni-MH battery)
DC9.6V (nickel-metal hydride
rechargeable battery)
AC Adapter
Input: AC 100 V to 240 V, 50 Hz to 60 H
Output: DC15V
Features
Apex locator, Customizable working length
determination, Adjustable volume,
Auto-calibration
Optional HF (high-frequency conduction)
module, 4 output modes including
electrocautery mode, Portable style
Components
5 × Contrary Electrodes
3 × File Holders
1 × Probe Cord
4 × Alkaline Dry Batteries (AA size)
3 × Wide Contrary Electrodes, 1 × Grip
1 × Foot Switch, 1 × Cap
1 × HF Probe Cord
1 × HF Relay Cord
1 × AC Adapter
1 × Battery Pack (nickel-metal hydride rechargeable battery)*
1 × Electrode Pen
3 × Electrode Holder
2 × Electrode C #10
2 × Electrode S #10L25
2 × Cutting Electrode No.1
*Built-in
Electrode Options
a. Electrode C #10 (2 pcs.)
b. Electrode C #25 (2 pcs.)
c. Cutting Electrode No. 1 (2 pcs.)
d. Electrode S #10L25 (2 pcs.)
e. Electrode S #25L25 (2 pcs.)
Configuration: Root ZX3 Apex Locator Accessories/Replacement PartsTRZX/RZX Mini/RZX3 Probe Cord, 1650mm (Order no. 248449422)Tri Auto ZX / Root ZX Contrary Electrodes, 5/pkg (Order no. 24107043)Tri Auto ZX / Root ZX File Holders, gray, 3/pkg (Order no. 244001981)Root ZX Long File Holder, 1/pkg (Order no. 248447047)Root ZX3 HF Module Accessories/Replacement PartsHF Probe Cord (Order no. 244000795)HF Relay Cord (Order no. 244000796)HF Foot Switch (Order no. 244000797)AC-Adapter for HF Charger with Multi-Region Connectors (Order no. 244003777)Battery Pack (Order no. 244000799)Grip (Order no. 244000800)Grip Cap (Order no. 244000801)Wide Contrary Electrode (Order no. 244000802)Electrode Holder (Order no. 244000803)Electrode S #10L25, 2/pkg (Order no. 244000804)Electrode S #25L25, 2/pkg (Order no. 244000805)Electrode S #40L25, 2/pkg (Order no. 244000806)Electrode Pen (Order no. 244000807)Electrode C #10, 2/pkg (Order no. 244000808)Electrode C #25, 2/pkg (Order no. 244000809)Cutting Electrode No. 1, 2/pkg (Order no. 244000811)
$1,122.99
$1,416.99
